HP Latex FS60W

Deliver stunning results with a superwide HP Latex FS60W printer that scales as your business grows.

All Products Back

Product Specification Brochure

Product Description

The HP Latex FS60W Printer is a powerful, scalable solution designed to maximize productivity and adapt to evolving business needs. With a wide 3.2-meter (126-inch) media capacity and high-speed performance—up to 89 m²/hr in color and 54 m²/hr in white—it’s ideal for high-volume, high-quality printing. It supports heavy-duty single rolls up to 300 kg (660 lb) and features large 10-liter color and 3-liter white ink cartridges for extended operation. Included accessories like the Jumbo Dual Roll Kit, Ink Collector Kit, and in-line slitters enhance workflow efficiency, making it a smart long-term investment for print professionals.

Enquire Now

Features

STUNNING—Quality that drives high margins

- You can grow into higher-margin jobs with up to30% wider gamut at high speed—preserving media gloss, feel.

- Stand out with a wide range of signage and décor applications—thin films, vinyl, odorless backlit textiles.

- Consistent color and quality configurations across your global fleet with HP Configuration Center.

‍

EFFICIENT—Scalability to optimize costs, workflow

- Integrate future enhancements with a scalable platform ready to meet evolving business needs.

- Meet tight turnarounds with speeds up to 89 m² (958 ft²) per hour today.

- Lower costs over time with upgraded 10L ink capacity and printheads that you can replace yourself.

- Print remotely and monitor fleet with HP LiveProduction included in HP Professional Print Service Plan.

‍

SUSTAINABLE—With environmental certifications

- This printer is built to last thanks to its scalable design.

- Create a comfortable workspace—water-based inks enable odorless prints and no hazardous air pollutants.

- Stand out with an offering that meets environmental certifications like UL ECOLOGO®and UL GREENGUARD.

- Contribute to the circular economy with HPPlanet Partners and PVC alternative media profile database.

‍

Applications

Banners

Print saturated banners at up to 958 ft²/hr (89 m²/hr)³ using PVC-free materials and achieve up to 30% wider color gamut.¹ PVC-free banners combined with water-based HP Latex inks increase the sustainability of your offering and help you generate new business from eco-conscious customers.

Canvas and wallpapers

‍

Print saturated color on canvas and wallpapers at 743 ft²/hr (69 m²/hr).¹³ Water-based Original HP Latex inks are ideal for wallcoverings and surfaces—and come with the certifications that matter to your customers.

Window graphics

Print window graphics with opaque white at 484 ft²/hr (45 m²/hr).¹⁴ You can create a high-opacity finish on both transparent and colored media—making easy work of even three-layer prints. Take advantage of the overflood option to produce stunning interior window transfers.

Vehicle graphics

Produce eye-catching vehicle graphics at 734 ft²/hr (69 m²/hr).¹⁵ Prints come out dry and ready for immediate lamination. Flexible HP Latex inks facilitate installation as prints adhere to the complex shapes and curves of vehicles without cracking.

Backlit textiles

Print directly onto textiles at 527 ft²/hr (49 m²/hr).¹⁶ The HP Ink Collector makes working with porous polyester and cotton fabrics effortless. You can produce temporary or permanent decorative indoor applications with our impressive color gamut. And rely on HP Latex water-based inks to deliver odorless prints that can be used in sensitive environments.

Specifications

Print speed

1302 ft²/hr (2-pass); 958 ft²/hr (3-pass); 743 ft²/hr (4-pass); 527 ft²/hr (6-pass); 409 ft²/hr (8-pass); 312 ft²/hr (10-pass); 581 ft²/hr - White Spot(60%); 183 ft²/hr - White Overflood (100%); 108 ft²/hr - 3 Layers (60%); 36ft²/hr - 5 Layers

Print resolution

Up to 1200 x 1200 dpi

Technology

HP Latex Printing Technologies

Ink types

Water-based HP Latex Inks

Print Cartridges/Bottle,Number

9 (black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer, HP Latex Overcoat, white)

Print cartridge/bottle volume

10L (color); 3L (white)

Printheads

8 (6 HP Latex Universal, 2 HP Latex Optimizer), 1HP Latex White

Applications

Exhibition and event graphics; Decoration; Displays; Exterior signage; Indoor posters; Banners; Light boxes - film; POP/POS; Textile; Vehicle graphics; Wallpaper

Handling

Roll-to-roll, double-sided blockout, dual-roll (optional), roll-to-free fall(optional), ink collector (optional)

Maximum media width

126 in (single roll); 2 x 63 in (optional dual roll); 2 x 60 in (optional jumbo dual roll)
