• HP Latex Optimiser
• HP Latex Inks
• HP Latex printheads
• High-efficiency curing
• Easy maintenance and operation
• HP Optical Media Advance Sensor (OMAS)
• SAi FlexiPrint HP Edition
• HP Quick Substrate Profiling
• Colour consistency
• Automatic cutter
• Easy remote online operator training
General
Print speed
48 m²/hr - Billboard (2 pass)
16 m²/hr - Outdoor Plus (6 pass)
12 m²/hr - Indoor Quality (8 pass)
10 m²/hr - Indoor High Quality (10 pass)
6 m²/hr - Backlits, Textiles, and Canvas (16 pass)
5 m²/hr - High Saturation Textiles (20 pass)
Print quality color (best):
Up to 1200 x 1200 dpi
Print technology:
HP Latex Printing Technologies
Ink types:
HP Latex Inks
Number of print cartridges:
7 (black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer)
Print heads:
6 (2 cyan/black, 2 magenta/yellow, 1 light cyan/light magenta, 1 HP Latex Optimizer)
Print head nozzles:
2112
Print repeatability
Average <= 1 dE2000, 95% of colors <= 2 dE2000
Media
Finished output handling:
Roll feed
take-up reel (optional)
automatic cutter (for vinyl, paper-based media, backlit polyester film)
Media types:
Banners, self-adhesive vinyls, films, papers, wallcoverings, canvas, synthetics, (fabrics, mesh, textiles and any other porous materials require a liner)
Non-printable area (roll media):
5 x 5 x 5 x 5 mm
Roll maximum input:
1
Media width, maximum:
1371 mm
Roll maximum weight:
25 kg
Roll external diameter:
180 mm
Media thickness:
Up to 19.7 mil
Dimensions and Weight
Dimensions (W x D x H):
2307 x 840 x 1380 mm
Package dimensions (W x D x H):
2541 x 760 x 1250 mm
Weight:
174 kg
Environmental Ranges
Operating temperature range:
15 to 30ºC
Operating humidity range:
20 to 80% RH (non-condensing)
Acoustic
Acoustic pressure emissions:
54 dB(A)
Acoustic pressure emissions (standby):
38 dB(A)
Acoustic power emissions:
7.2 B(A)
Acoustic power emissions (standby):
5.5 B(A)
Power
Print speed
2.2 kW (printing)
70 watts (ready)
< 2.5 watts (sleep)
Certifications
ENERGY STAR® certified:
Yes
Environmental certification:
ENERGY STAR
WEEE
RoHS (EU, China, Korea, India, Ukraine, Turkey)
REACH
EPEAT Bronze
OSHA
CE marking compliant
