Powerful features that offer your business more flexibility and greater productivity
Envelope Feeder
The DS-700 iQ handles a wide range of envelopes from C6/5 to C4 and everything in between. Insertion is always done wide-edge first (wallet-style) which gives greater control and allows for thicker packs, up to 10mm. Simply adjust the self-centering side guides and back stop for the envelope type, load the hopper and select the appropriate job from the run screen. Adjustments for the pack size and opening of the envelope are all automated, so the machine automatically drives the envelope stack to the feed wheels and begins inserting the job right after pressing the Start button.
Output Processing
Choose from a large variety of output options using a simple conveyor, sorters, or postage meter choices. Personalise communications using a dynamic envelope printer. Print individual recipient details, return addresses, marketing slogans or pre-paid indicia with data provided as part of the closed loop integrity process. Design layouts and fonts, up to 600dpi, to suit each application for a truly unique mailpiece. You can even rotate large-format envelopes before printing to present in a portrait style.
Feeder-Folder
The multi-functional Feeder Folder module eliminates the need to pre-fold enclosures. It does it for you. For enclosures the Feeder-Folder supports Single, C and Z-folds, but inserts may be fed as well. Full page reading from top or bottom is available as an option, supporting OMR, BCR, 2d or QR reading. Up to 8 Feeder-Folders can be placed in-line.
Versatile Insert Feeders
Feed inserts from a 100mm (4”) voucher to a full A4 on the Versatile Insert Feeders with thickness ranging from a single 80gsm sheet to a 6mm (1 /4”) booklet. The high-capacity hoppers hold up to 250mm (10”) of materials and can be reloaded on-the-fly while a job is running for maximum efficiency. The optional fullpage scanners can be licensed to read OMR, BCR, 2d and QR codes and used for either matching personalised inserts with a prime document from the Tower Folder, or as the prime document for applications such as invoices or reports.
Tower Folders
Tower Folders come in five variants to suit your business needs with a document accumulation speed of 8,000 or 14,000 documents per hour. The size and number of feeders may be customised depending on the volume and mixture of documents for insertion in each job. The Compact Tower has a maximum capacity of 1,000 sheets with either two feeders of 500 sheets or one feeder of 1,000 sheets. The Standard Tower has a total capacity of 2,000 sheets and can be configured into combinations of 500 or 1,000 sheet feeders. Towers can be equipped with full-page scanners, allowing for face-up and face-down loading and can be licensed for OMR, BCR, 2d or QR codes. Compact towers can have one scanner and Standard Towers can have up to two scanner. Scanners are optional. Load documents in a portrait style for folding, or landscape for larger envelopes. Three fully-automated fold plates adjust to suit the envelope chosen with C, Z, V or double-parallel fold patterns. Up to 8 pages can be accumulated and folded together, while sets of more can be accumulated at the inserter head before insertion. For C4 envelopes, up to 80 sheets can be collated before insertion. To minimise idle time, the restart button can be used after refilling the feeders.
Wide-Screen
User Interface The DS-700 iQ can be configured with the appropriate modules to suit your organisation. Should those needs change over time, the DS-700 iQ’s modular design can be easily adapted to your desired configuration to meet the demands of your business. Control every aspect of the DS-700 iQ via its intuitive Touch-Screen using the latest generation IMOS software. Once each job has been created using the step-by step Wizard, it can be run at any time simply by recalling the job from the menu. Folding, pack size and envelope adjustments are all made automatically. Password controls ensure operator, supervisor and service roles are distinguished for efficient processing.
