Max booklet 1-up production speed
4,600 A5-booklets up to 10 sheets5,200 105x200mm-booklets up to 5 sheets
Max booklet 2-up production speed
Up to 9,000 booklets/hr 2-up booklets (2-up production)
Max booklet thickness
6 mm (30 sheets of 80 gsm, 120 page booklet)
Flat sheet sizeMax flat sheet size over 500 mm in length
Max 350 mm (W) x 508 mm (L)Max 230 mm (W) x 610 mm (L)Min 120 mm (W) x 170 mm (L)Min 105 mm (W) x 297 mm (L)
Finished untrimmed booklet size1-up production
Max 350 mm (W) x 254 mm (L)Min 120 mm (W) x 85 mm (L)
Min 105 mm (W) x 148.5 mm (L)
Finished booklet size 1-up production
Max booklet size over 500 mm in length
Max 350 mm (W) x 254 mm (L)Min 120 mm (W) x 75 mm (L)
Min 105 mm (W) x 75 mm (L) (12 pages max)
Max 230 mm (W) x 305 mm (L)
Finished booklet size 2-up production (DKT-200)
2 stitches in each booklet (centered)2 stitches in each booklet (non-centered)1 stitch in each booklet (centered)
Max 171 mm (W) x 254 mm (L)
Min 114 mm (W) x 75 mm (L)Min 105 mm (W) x 75 mm (L) (12 pages max)Min 90 mm (W) x 75 mm (L) (12 pages max)
DBM-600T Trimmer Front KnivesMax trimming thickness
1 to 25 mmUp to 75 mm with 12 pages or lessWithin 6 mm
Folding capacity
2-30 Sheets
Fine adjustment
From 0.1 mm
Max stitching capacity
3 mm (30 Sheets of 80 gsm)
Min/Max Stitching Head distance (1-up)
60 - 320 mm
Stitching Head distance (2-up)
58.5 mm (55 mm In Fine Adjustment Mode)
Stitching Heads
Standard fitting: 2x Hohner 43/6S
Optional 4 Hohner Flat/Loop heads
Controls
PC Controlled job programming, save and recall, automated set-upMicrosoft Windows-based GUI (Graphical User Interface)Individual control panel for Fine Adjustment
Job memories
Infinite from PC Controller
Folding Rollers
Automatic mechanism
Error Detect Sensors
Stitching wire, paper feed, paper jam, safety guards
Features
Quick and automatic job changeover Straight paper path with LED lightingCentre Registered SystemClear view, wide and easy access within the modules
DBM-600 Options
DBM-600 Sheet by Sheet Air Kit (Multiple Sheet FeedingDBM-600 Offset Trim with manual control (from 1 To 21 mm)Hand Feed Kit (DBM-600 manual feeding)
Optional DKT-200 Head and Foot Knives
Max trimming thickness
DKT-200 Options
Max/Min Trim 2-60 mm
30 mm Max Trim for each knife
6 mm Gutter Cut knives1-up: 6mm
2-up with Gutter Knife: 2.4mm
Hole Punch Unit: 3mm
DKT-200 Offset Trim with manual control (from 1 to 21 mm)
6.4 mm diameter 2 Hole Punch
Kicker/Batching Unit
Connecting devices
Up to 6 x DSC-10/60i Collating Towers DCR-ST Criss Cross StackerDKT-200 Head and Foot TrimmerDBM-600T/DKT-200 Long Delivery Conveyor (DBM-LSW)Paper extractor device
Power Supply
220 - 240V 50/60Hz (DBM-600: 2.5A/DBM-600: 3.4A)
Power consumption
DBM-600: 465 W - DBM-600T: 645 W
Dimensions - DBM-600 Net weights DBM-600 Trimmer
DKT-200 & LSW
ASM + Feeding System
Unique Total Feed Control on Each Bin
1848 mm (W) x 929 mm (D) x 1227 mm (H) - 377 kg
716 mm (W) x 717 mm (D) x 1124 mm (H) - 233 kg
2302 mm (W) x 700 mm (D) x 1169 mm (H) - 472 kg
Ability to increase the flow of air and vacuum on each bin
Ability to adjust and feed timing
